Depth‑First Search (DFS)

Finished :sunglasses:

What is DFS? :thinking:

Depth‑First Search (DFS) is a graph‑traversal algorithm that explores as far as possible along each branch before backtracking.

Algorithm (pseudocode) :grin:

So the key idea is last in first out (LIFO)


DFS(G, s):
    create an empty stack S
    mark s as visited and push s  ➜  S ← [s]
    while S is not empty:
        u ← pop(S)
        for each neighbour v of u in reverse‑sorted(G.neighbours(u)):
            if v is unvisited:
                mark v as visited
                push v  ➜  S ← S ∪ {v}

Time complexity: \(\mathcal{O}(|\mathcal{V}|+|\mathcal{E}|)\) Space complexity: \(\mathcal{O}(|\mathcal{V}|)\) (It uses a queue to keep track of the vertices that need to be visited.) Usage - cycle detection, topological sort, articulation points, maze generation, etc.

Visualization :look:

The animation below is generated with Manim. It shows DFS expanding a queue and colouring vertices/edges in the order they are discovered.

DFS Example

Check Source Code for Visualization
